MIXA60WB1200TEH IXYS IGBT MODULE 1200V 85A 290W E3
MIXA60WB1200TEH Images
MIXA60WB1200TEH Images
  • Manufacturer: IXYS (Littelfuse)
  • Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: E3
  • Description: IGBT MODULE 1200V 85A 290W E3
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MIXA60WB1200TEH Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MIXA60WB1200TEH Specifications:
  • MfrPart.: MIXA60WB1200TEH
  • Mfr: IXYS
  • Description: IGBT MODULE 1200V 85A 290W E3
  • Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
  • Package: Box
  • Series: -
  • PartStatus: Active
  • IGBTType: PT
  • Configuration: Three Phase Inverter with Brake
  • Voltage-CollectorEmitterBreakdown(Max): 1200 V
  • Current-Collector(Ic)(Max): 85 A
  • Power-Max: 290 W
  • Vce(on)(Max)@VgeIc: 2.1V @ 15V, 55A
  • Current-CollectorCutoff(Max): 500 µA
  • InputCapacitance(Cies)@Vce: -
  • Input: Three Phase Bridge Rectifier
  • NTCThermistor: Yes
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • MountingType: Chassis Mount
  • Package/Case: E3
  • MIXA60WB1200TEH IXYS (Littelfuse), IGBT MODULE 1200V 85A 290W E3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
MIXA60WB1200TEH, IXYS authentic parts in stock from IXYS (Littelfuse) authorized distributors, order today, can ship immediately.
